Description
- Class 1 e-bike with a pedal-assisted speed up to 20 mph.
- Up to a 40-mile range on a single charge.
- Monitor level of power support and battery charge with the LED controller.
- The 7-speed derailleur adds extra range for getting uptown and back downtown.
- Turn your e-bike into a me-bike by adding accessories from our Fern collection, or choose from our e-bike essentials.
- Rely on a network of 3,000+ Electra retailers for service and support when you need it.
Artist Series: Loft Go! Dusk and Dawn
First light sheds bright shades of pinks and oranges across the sky. Loft Go! Dawn embodies that scene with a coral fade frame accented by cream touchpoints. In contrast to the morning hours, Loft Go! Dusk appeals to a different crowd with its deep indigo frame. Hand drawn illustrations depict eclectic streets spanning decades of architectural design to create a unique skyline. Featuring a step-thru frame, these e-bikes have the universal appeal of an urban ride that speaks to all.
Build Your Bike
Did your dream bike just arrive at your doorstep? Ready to add the finishing touches? If so, you came to the right place. Please read your Quick Assembly Guide and click here to watch additional step-by-step instructions.
Compliant with leading safety regulations
The e-systems on Trek and Electra e-bikes are third-party tested to meet the latest e-bike safety regulations, including the stringent UL 2849 certification — so all you have to worry about is where your e-bike will take you next.
| Frame | 6061-T6 aluminum |
| Fork | Hi-ten steel unicrown, straight/tapered leg |
| Tire | 700x40mm city tread |
| Hub Front | Alloy low-flange w/6-bolt disc, 32h, nutted |
| Rim | Alloy double walled 700x32h // Alloy double walled 700x36h |
| Spokes | 14g stainless steel, silver |
| Shifter | Shimano Tourney Revo 7-speed twist with optical gear display |
| Rear Derailleur | Shimano Tourney TY300 |
| Bottom Bracket | Torque sensor, threaded, 122.5mm spindle |
| Cassette | 14-34, 7 speed freewheel |
| Chain | KMC Z7, 7 speed |
| Chainring | Forged alloy 170mm, 44t chainring |
| Brake | Mechanical disc, 160mm rotor, flat-mount // Mechanical disc, 160mm rotor, flat-mount |
| Brake Lever | Alloy, 3-finger |
| Pedal | Alloy platform w/non-slip rubber tread |
| Saddle | Retro leatherette w/dual spring |
| Seatpost | Alloy micro-adjust 27.2x400mm |
| Handlebar | Alloy custom bend low-rise, 640mm width |
| Stem | Cast alloy 25.4mm quill, 92mm extension |
| Headset | 1 1/8'' steel threaded |
| Grips | Hand-stitched leatherette |
| Fender | Alloy extruded, painted |
| Light | Spanninga, LED, taillight // Herrmans H-Black MR4-E, 120 lumen, 40 lux, LED, headlight |
| Kickstand | Alloy, rear mount |
| Battery | 250Wh, integrated in down tube |
| Motor | Hyena hub drive motor, 250W |
| Charger | 2A, 42V output, 100V-240V AC input |
Geometry Chart
| Frame Reach | 38.8 |
| Frame Size Letter | M |
| Frame Stack | 60.5 |
| Head Angle | 68.0° |
| Head Tube Length | 18.5 |
| Seat Tube | 48.5 |
| Seat Tube Angle | 66.5° |
| Standover | 55 |
| Wheelbase | 116.5 |
| Wheel Size | 700c |
| Color | STARDUST |
| Size | M |
